Energy Storage Harness

Overview
This cable connects equipment fitted with an SB50 connector to a bolted connection point, such as a battery terminal, bus bar, or terminal block. It is used in EV motorcycle and battery storage wiring.

Specifications
- Connector A: SB50
- Connector B: Ring terminal
- Standard ring terminal size: M6. M8 is available by custom request before ordering.
- Wire gauge: 10AWG
- Conductor: Pure copper
- Rated current: 50A
- Rated voltage: 600V DC
- Construction: Heat-resistant nylon and red/black braided protective sleeve
- Cable colors: Red and black
- Length: 50cm / 100cm / 300cm (select option)

Package Contents
- 1 × SB50 to ring terminal cable (M6 ring terminals), length per selected option

M8 Ring Terminals
M8 ring terminals are not a standard option. To request M8, contact us at support@sulyt.com before ordering. M8 orders are made to order and are covered by the Custom and Made-to-Order Products section of our Refund Policy.

Before You Order
Check the connector type and polarity on the equipment you are connecting, and confirm that the cable's ratings are suitable for your system according to your equipment manufacturer's specifications. If you are unsure, contact us at support@sulyt.com before placing your order.

Custom Orders
Need a different cable length or connector combination? Contact us with your requirements. Our team will review the information and reply by email with questions or available next steps.
