How to Choose the Right Connector

Different connectors are designed for different current ratings, environments, and applications. Use the comparison table below to find the right model for your setup.

Product Comparison Table

Model Rated Current Waterproof Rating Best For
XT90-S (Anti-Spark) 90A None RC cars, drones, battery-to-ESC connections
QS8 to XT90 Adapter Cable 45A IP67 RC & EV cross-format adapter, mixed setups
Anderson SB50 Cable 50A / 600V DC None E-moto, EV battery charging, industrial use
AS150 Female Connector 150A None High-current EV battery packs, high-power discharge
MR60 Male & Female Pair 60A None RC motor-to-ESC connections, battery interfaces
M23 Push-Lock Right Angle Connector 50A IP67 E-bike, e-scooter, motorcycle charging port
Light Array One Piece Harness — — Integrated light array wiring, plug-and-play
Plug-and-Play Lighting Harness — — Universal lighting upgrades, no soldering required
Back Bone Wiring Harness – Roof Rack — — Roof rack lighting and cable routing

Quick Selection Guide

  • RC Racing / Drones: Choose XT90-S — anti-spark design protects your ESC and battery on first connect
  • Electric Motorcycle / E-Moto Builds: Choose AS150 (high current) or Anderson SB50 (charging applications)
  • E-Bike / E-Scooter Charging Port: Choose M23 — IP67 rated, safe for outdoor and wet conditions
  • Adapting Between Different Connector Types: Choose QS8 to XT90 Adapter Cable
  • Full Vehicle Lighting Wiring: Choose from the Custom Wire Harness series

Frequently Asked Questions

What is the difference between XT90 and XT90-S?

The XT90-S features a built-in anti-spark resistor that prevents arcing caused by capacitor inrush current on first connection. It is strongly recommended for large-capacity battery packs.

What does IP67 waterproof mean?

IP67 means the connector can withstand temporary immersion in water up to 1 meter deep for 30 minutes. Suitable for outdoor, rainy, or high-humidity environments.

How do I know if a connector's current rating is sufficient for my system?

We recommend choosing a connector rated at least 20–30% above your system's peak current draw to ensure a safe operating margin.

Support & Service Center


Empowering your connections. Whether you
bought a standard cable, need small-batch wholesale,
or are developing a highly customized OEM prototype,
our engineering and support teams are here to help.



Browse Standard Catalog
Request a Custom Quote

Sunluytom

Standard Wire Harnesses

Applications: E-Motorcycle standard replacements, standard solar MC4 extensions, basic battery cables.

Support: Downloadable Pinout Diagrams; Step-by-step waterproof connector assembly videos; Instant replacement requests for retail orders.

Support Request

Sunluytom

Highly Customized & Non-Standard

Applications: Concept E-Motorcycles, proprietary Home Energy Storage walls, unique solar farm grids.

Support: Prototype Validation (Submit feedback for your 1-set custom order); Design Revisions (Upload updated requirements); Scaling Up (Start OEM Onboarding for 100+ pcs).

Support Request

Warranty & Returns FAQs

A: All standard wire harnesses sold via our Shopify store come with a 12-month standard warranty covering manufacturing defects, terminal crimping failures, and IP-rating compromises under normal use.

A: Because custom harnesses (from 1-piece prototypes to OEM batches) are built exclusively to your specifications, they are non-refundable. However, if the product fails to meet the agreed-upon CAD drawing or fails our 100% continuity test, we will rework or replace it free of charge.

A: We offer a 30-day hassle-free replacement for standard products. Please submit a ticket with your Order ID and a clear photo of the damage, and we will ship a replacement within 24 hours.

A: For applications exposed to harsh environments, please provide photos showing the installation context. Our engineers need to verify that the cables were routed correctly to validate the warranty claim.
